Scale-O-Matic S302

Dimensional Specifications

Footprint, height, and electrical requirements for the S302 dough divider rounder.

Scale-O-Matic S302 dimensional drawing showing footprint, height, and clearances
2,000
Pieces per hour
75 lb
Hopper capacity
1 - 32 oz
DIVIDING RANGE
3 HP
Total motor power

Dimensions & Electrical

Physical Dimensions
Overall Width63.25 inches
Overall Depth29.5 inches
Overall Height68.5 inches
Hopper Height56.5 inches
Conveyor Height (adj.)Adjustable — folds for storage
Footprint30 x 66 inches
CastersLocking swivel — fully mobile
Electrical & Mechanical
Divider Motor2 HP
Rounder Motor1 HP
Total Power3 HP combined
Voltage208 - 230 VOLTS (STANDARD) optional voltages available
Phase3 PHASE, 20 AMP (STANDARD) Single phase optional
ControlsSeparate divider & rounder controls
CertificationsMachine ETL listed, Control Panel UL Listed

Complete Technical Specifications

Model
Scale-O-Matic S302 (also S300)
Dividing Range
1 oz – 32 oz (with optional dividing cups)
Production Rate
Up to 2,000 pieces per hour
Hopper Capacity
Standard 75 lb. Optional 125 lb. available
Divider Motor
2 HP
Rounder Motor
1 HP
Cabinet Material
All stainless steel
Mobility
Locking swivel casters
Conveyor
Adjustable height take-off conveyor, folds for storage
Operation
Single-person operation; separate controls for divider and rounder
Weight Adjustment
Crank adjustment — no tools required
Lubrication
Automatic oiling system on divider
Cleaning
Rounder and divider disassemble easily with provided tool
Certifications
Machine ETL listed, Control Panel UL Listed
New Unit Price
From $36,278
Used Unit Price
From $18,500 (tested & working, pending availability)
